Introducing the Cast Steel CF8M 24" 600LB RF Flange Double Offset Butterfly Valve. This high-quality valve is designed to meet the needs of various industries with its exceptional features and reliable performance.
Nominal Diameter: 24”
Bore: Full Bore
Nominal Pressure: 600LB
Material: CF8M
Operation: Gear Box
Design Standard: API609
Test/Inspection: API598
End Connection: RF FLANGE
Flange standard: ASME/ANSI B16.5
Top Flange: ISO5211
In summary, the Cast Steel CF8M 24" 600LB RF Flange Double Offset Butterfly Valve offers exceptional performance and reliability. Its robust construction, precise operation, and adherence to industry standards make it an ideal choice for various applications. Trust in this valve to meet your needs and deliver superior performance.
Introduction of Double Offset Butterfly Valve:
Primarily designed to meet the stringent requirements and safety levels of the oil & gas industry, this high performance butterfly valve is available in a range of sizes, from 3 inches to 24 inches (DN 80-600). This makes them ideally suited for a host of applications, including firewater, hydrocarbons, cargo handling, bilge and ballasts and utilities, just to name a few.
Manufactured to ASME 150 and 300 standards, features a soft polymer seat. Customers can specify PTFE, RTFE or UHMWPE seats, depending on their application and the performance characteristics required.
The new valve is available in a choice of body materials , carbon steel for general applications, 316 stainless steel and duplex stainless steel for applications requiring superior corrosion resistance.
Description:
polymer and elastomer seats provide bi-directional, drop-tight shut-off in vacuum as well as at full rated differential pressure. Its unique design does not rely on pressure to assist sealing therefore seals at high and low pressures, as well as dirty services. A variety of materials allows optimum seat life in all applications.
Blow-out resistant shaft is standard on all valves for increased safety.
Unique packing design allows for use in pressure as well as vacuum without modification or special assembly.
Disc taper pins are tangentially positioned half in disc and half in shaft, placing them in compression rather than shear, which eliminates potential for failure.
Rocker-shaped gland bridge compensates for uneven adjustment of gland nuts reducing packing leaks.
Integrally cast disc position stop perfectly locates the disc in seat, achieving maximum seat and seal life.
Extended neck allows for 50 mm (2″) of pipeline insulation.
Integrally cast mounting pad provides direct mounting of actuators eliminating the need for costly brackets and couplings.
Flattened body bore at shaft journal ports positions shaft bearings near disc, providing maximum shaft support resulting in reduced wear and longer life.
Application:
Modulating service
Airport refueling
Hydrocarbon processing
Chemical/petrochemical processing
Purified gas
Steam and vacuum services
Power and utilities
Refrigeration
HVAC
Alumina refining
